Item# INFREFERENCE1270
Infinity

Reference Subwoofers 1270

Details

10" and 12" car audio subwoofers


Variations
Highlights

Reference woofers delivers the enhanced efficiency and higher output. INFINITY uses progressive spiders to provide the best possible control at the excursion limits versus much more commonly used linear spiders. The benefit is a far more controlled woofer stroke with far tighter bass characteristics. With high-roll surrounds, proprietary cone design and long-excursion, Reference woofers deliver deep, powerful bass, with greater accuracy than conventional woofer. And the exclusive SSI™ (Smart Selectable Impedance) switch lets you choose 2- or 4-ohm impedance for maximum configuration flexibility. It’s everything you want in a woofer.

Know What's In The Box

  • 1 x Reference 1270
  • 1 x Woofer 12”
  • 1 x Owner’s manual

Product Specs, Manuals, Compatibility & Features

Documents & Downloads

The latest owner's manuals, quick start guides, and documents.

General Specifications

Description
12" (300mm) car audio subwoofer
Woofer
12" (300mm)
Power Handling
275W RMS, 1100W peak
Sensitivity (@ 2.83V)
93dB
Frequency Response
25Hz – 175Hz
Impedance
2 or 4 ohms, switch-selectable

Dimensions

Cutout Diameter
11-1/4" (285mm)
Mounting Depth
6-1/2" (165mm)

Features

SSI™ (Selectable Smart Impedance)

Stadium subwoofers feature an exclusive dual impedance switch that lets you choose either load impedance option. This allows for a variety of system configurations when using one subwoofer or multiples. Not available from any other manufacturer, SSI lets you reconfigure your system by simply flipping a switch.

High-roll surround

Reference woofers incorporate a high-roll surround that provides superior cone edge suspension while maximizing excursion. It not only increases the cone area, it also provides remarkable linear stability and reliability.

Proprietary cone design

INFINITY subwoofer cones aren’t just built to thump, they’re built to last. Reference woofers feature an exclusive cone design that delivers superior rigidity for long-lasting performance

Long excursion design

The longer a subwoofer’s excursion is,the more air it moves. And the more air it moves, the more bass you feel. The long-excursion design in Reference subwoofer ensures big, deep bass output. Just the way you like it.
